A fee proposal can promise coordinated drawings while leaving the loads, performance criteria, exclusions, and approval gates undefined. By the end of your review, you will have a practical way to test the consultant’s inputs, Basis of Design, technical deliverables, equipment choices, operating risks, fees, programme, and commissioning commitments before authorising design.
Key takeaways
- Confirm site conditions, loads, schedules, utilities, and expansion plans before design starts.
- Audit the Basis of Design against measurable indoor conditions and available plant capacity.
- Compare lifecycle cost, resilience, maintainability, controls, and commissioning evidence—not just first cost.
- Make handover documents, training, warranties, and performance testing contractual deliverables.
What information and commitments must be defined before design starts?
1. Do not start design until the consultant can work from evidence rather than allowances. Provide the site survey, floor plans, climate data, occupancy schedule, operating hours, equipment heat loads, process loads, utility capacities, indoor-air-quality targets, and future expansion requirements. Ask who will verify existing electrical, water, drainage, roof, plant-room, access, and structural conditions.
2. Use an HVAC consultant proposal checklist to test the HVAC design scope. The proposal must identify surveys, load modelling, energy analysis, authority submissions, tender support, construction administration, testing and balancing, commissioning, and as-built documentation.
Require named deliverables, review cycles, approval gates, and explicit HVAC design assumptions and exclusions; reject “by others” unless it names the responsible party and interface.
3. Check the HVAC design fee proposal and programme before approval. Confirm whether the fee is fixed, hourly, staged, or tied to construction value, and price redesign after an owner change. The programme must show data collection, concept selection, Basis of Design approval, 30%, 60%, 90%, and issued-for-construction reviews, procurement support, and handover.
Make each stage a written approval gate, with responsibility for unresolved comments recorded before the next stage begins.
How do you audit the Basis of Design before approving it?
Audit the approved Basis of Design HVAC as a controlled project requirement, not a narrative appendix. Reject vague statements such as “adequate ventilation” or “ASHRAE compliant”; require numbers, assumptions, responsible parties, and the exact code editions used.
- Verify the weather file and outdoor design conditions, indoor temperature and relative humidity setpoints, outdoor-air quantities, total air-change targets, filtration stages, diversity factors, zoning logic, redundancy, operating schedules, and utility capacities.
- For healthcare spaces, require separate entries for ASHRAE Standard 170 outdoor air, total air changes, filtration, and pressure relationships. Also name the adopted FGI Guidelines edition and every state or local amendment; “FGI” alone does not identify the governing rule.
- Compare the BOD with the HVAC load calculations and demand an auditable file showing envelope assumptions, internal and process gains, sensible and latent ventilation loads, schedules, weather data, diversity, and future expansion.
Review peak cooling and peak heating loads, not peak tonnage alone. Ask how ventilation loads change coil, reheat, dehumidification, and central-plant capacity.
| Review item | BOD evidence | Load-model evidence |
|---|---|---|
| Cooling and heating peaks | Design capacities and operating mode | Hourly or design-day peak sensible and latent results |
| Ventilation | Outdoor air and total air changes listed separately | Ventilation heating, cooling, and dehumidification loads |
| Future capacity | Expansion allowance and utility reserve | Added loads, schedules, and diversity assumptions |
Do not approve until every difference between the BOD and model has an explanation, revision record, and named approver.
Which design documents and alternatives should you compare?
Approve only after reviewing HVAC design deliverables that show how capacity, distribution, controls, and coordination will work in practice.
- Load calculations and equipment schedules, including design conditions and turndown
- Duct and pipe layouts with pressure-drop calculations
- Single-line diagrams and control sequences
- Specifications and coordinated drawings
- Energy models tied to operating hours, utility rates, and expansion loads
Compare every option against the same load, operating-hours, utility, maintenance, and expansion assumptions.
| Alternative | Compare | Record |
|---|---|---|
| Chilled water versus DX | Plant response, refrigerant exposure, maintenance, and part-load operation | First cost, demand, water use, footprint, noise, refrigerant implications |
| CAV versus VAV | Zoning, ventilation control, fan energy, and turndown | Comfort, controls complexity, service access, life-cycle effort |
| Air-cooled versus water-cooled chillers | Ambient derating, cooling-tower water, sound, and maintenance | Capacity at design conditions, water use, replacement access, service availability |
| Central plant versus packaged equipment | Distribution losses, redundancy, footprint, and expansion | Electrical demand, acoustic impact, spare-parts support, installed and operating effort |
Test equipment at the project’s ambient temperature, altitude, fouling condition, filtration resistance, duct and pipe losses, and control limits. Catalogue capacity is not delivered capacity. Check service clearances, acoustic criteria, redundancy, feeder capacity, local maintenance capability, and replacement routes.
For cold storage, require product-temperature assumptions, pull-down and recovery calculations, door-opening profiles, defrost strategy, power-loss response, alarm escalation, and temperature mapping. Review refrigerant classification under ASHRAE Standard 34 and system safety under Standard 15, including charge, leak detection, ventilation, relief discharge, and occupied-space exposure.
Will the proposed system protect occupants, products, and critical operations?
A system that holds a room setpoint can still spread contaminants, spoil products, or interrupt critical work. Approve it only after an HVAC ventilation review connects each safeguard to occupancy and process.
1. Check outdoor-air quantities, exhaust paths, room pressure relationships, filtration stages, heat recovery, carbon-dioxide monitoring, and contaminant controls. The indoor air quality design must match occupancy, equipment, chemicals, pathogens, and process emissions.
2. Reject a pressure schedule that says only “positive” or “negative.” Require the pressure reference, airflow direction, minimum differential or control criterion, door-opening behaviour, transfer-air path, alarm threshold, and failure response, including loss of the air-handling unit or exhaust fan.
3. For a healthcare renovation, require an infection-control risk assessment and infection-control construction plan before approving phasing or temporary HVAC. Price and assign barriers, negative-air machines, filtration, monitoring, work phases, and protection of adjacent occupied clinical areas.
4. For pharmacies and controlled environments, identify whether the requirement is an ISO 14644-1 particle classification, a compounding standard, a temperature and humidity limit, or microbial control. ISO 14644-1 classifies airborne particles; it does not establish sterility or compounding compliance.
5. Test redundancy against the consequence of failure, including isolation valves, electrical feeds, maintenance conditions, generator operation, and preservation of pressure, temperature, humidity, ventilation, and alarms. In cold storage, verify product temperatures—not room-air setpoints—using sensor location, stratification, loading, evaporator placement, door openings, pull-down, recovery, and temperature mapping.
Are the commercial terms, controls, commissioning, and handover ready for approval?
Do not approve commercial terms until a responsibility matrix assigns design, coordination, procurement support, installation review, testing and balancing, controls integration, commissioning, training, and defects correction. Name each party, deliverable, due date, and acceptance authority; “by others” is not an assignment.
Separate the HVAC commissioning scope from design completion. Require a commissioning plan, design reviews, submittal review, startup checks, controls point-to-point verification, functional performance testing in relevant modes, operator training, issue tracking, and an owner’s systems manual. A points list or trend log is not a functional test.
- Require HVAC controls sequences for occupied and unoccupied operation, warm-up, cool-down, economizer operation, airflow loss, smoke or fire alarm, dirty filters, sensor failure, network loss, generator operation, and manual override.
- Define BAS cybersecurity boundaries, remote-access rules, credential ownership, backups, restoration, patching, alarm retention, and clinical or enterprise-network interfaces. BACnet interoperability does not prove cybersecurity.
- Confirm equipment access and replacement routes, maintenance clearances, condensate and humidifier-water treatment, roof penetrations, medical-gas and electrical coordination, TAB procedures, spare parts, and controls as-builts. These commitments belong in the HVAC handover documentation.
- Tie payment and final acceptance to closed commissioning issues, verified sequences, training records, and delivered as-builts. A consultancy such as Arete Consulting Engineers adds value when its proposal covers these interfaces instead of stopping at design drawings.
